Emerson TS1 Series Datasheet

TS1 Series
Temperature Controls
Alco Controls
D A T A S H E E T
TS1__35038_EN_R05.doc 4 / 8 10.08.2011
Nomenclature
The following chart explains the nomenclature of the TS1
controls for ease of reference. The basic structure is that of a
three digit Product Name followed by a three digit code,
describing Function, Temperature Range and Temperature
Sensor.
Customised versions, which deviate from standard catalogue
products are available on request and use a different Product
Name. They are called TSA followed by the three digit code to
indicate function, temperature range and temperature sensor.
Technical data
Environmental conditions Electrical contacts
Ambient temperatures Type of contacts 1 x SPDT contact
storage and transportation:
operation:
-50 °C to +70 °C
-50 °C to +70 °C
Contact material - standard:
- options:
CuAg
3
gold plated contacts
Maximum temperature at sensor bulb depending on bulb Heating load (AC1): 24A / 230 V AC
Locked rotor / Startup (AC3): 144A / 230 V AC
type and charge Inductive load (AC15): 10A / 230 V AC
Dust and water protection
EN 60529 / IEC 529:
Control mounted flush against wall!
IP44 (w/o off-switch)
IP30 (with off-switch)
Inductive load (DC13):
0.1A / 230 V DC
3A / 24 V DC
6A / 12 V DC
Vibration resistance: 4 g @ 10 … 1000 Hz Motor rating UL (FLA): 24A / 120/240V AC
Approvals
Locked rotor UL (LRA): 144A / 120/240V AC
Low Voltage Directive all models Bellows heater (sensor types A, E, P -
73/23/EWG 93/68/EWG;
EN 60947-1 / 60947-5-1 / 60730-2-9
(CE-Label) not for frost monitors function C or D):
- option:
82 k, 230V AC, DC
12V, 24V rating
Germanic Lloyd: standard models
Materials
when used with marine cable glands (accessory) Housing materials
cover:
Polycarbonate (PC)
UL / CSA:
all models (pending)
frame: Steel, yellow chromated
Type code
TS1
-
Function / housing variant
A = Wall mounting, top adjustment
B = Wall mouting, top adjustment, off-switch
C = Frost monitor, auto reset
D = Frost monitor, manual reset
E = Wall mounting, front adjustment
F = Wall mounting, front adjustment, off-switch
G = Flush mounting
H = Flush mounting, off-switch
R = Wall mounting, top adjustment, manual reset*
*temp. ranges 0 – 4: manual reset for falling temperature
temp. ranges 5 – 9: manual reset for rising temperature
Temperature Sensor Type
A = Vapour charge, 2 m, bulb
E = Vapour charge, 0 m, coil
F = Adsorption charge, 2 m, bulb
P = Vapour charge, 2 m, capillary
function „C“ and „D“: 6 m capillary
Tempera
ture range
0 = +4.5 … + 20 °C
1 = -45 … -10 °C
2 = -30 … +15 °C (-30 … +10 °C)
3 = -10 … +35 °C (-10 … +25 °C)
4 = -25 … +30 °C (-30 … +35 °C)
5 = +20 … +60 °C (+25 … +75 °C)
6 = +50 … +100 °C
7 = 0 … +10 °C
() = dep. on exact version
Product Name
TS1 = Adjustable thermostat
TSA = Customised version
