20031110 3-2-1 H94X1CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTE:
Parts that are not assigned part numbers (---------) are
not available.
Comparison Chart of Models and Marks
Model Mark
EWD2203 A
EWD2003 B
Ref. No. Mark Description Part No.
A1X A FRONT ASSEMBLY H9410UD 0VM204041
A1X B FRONT ASSEMBLY H94A4UD 0VM204460
A2 TOP COVER H9400UD 0VM101208
A3 CHASSIS(E4+U27) H9400UD 0VM101207
A4 PANEL, REAR H9410UD 0VM204006
A8 A DOOR, CASSETTE H9410UD 0VM305940
A8 B DOOR, CASSETTE H94A4UD 0VM416103
A9 SPRING, DOOR H7220UD U15 0VM408617
A10# A LABEL, RATING(U) H94X1UD or ----------
# A LABEL, RATING(D) H94X1UD ----------
A10# B LABEL, RATING(U) H94X2UD or ----------
# B LABEL, RATING(D) H94X2UD ----------
A14 LABEL, BAR CODE HB400UD ----------
A14 A LABEL, BAR CODE H9410UD ----------
A14 B LABEL, BAR CODE H94A4UD ----------
A18 LABEL, TELEPHONE NUMBER
H7931UD(EMERSON)
----------
A19 HOLDER, EAS(H9410UD) MAKER
NO.EM150DR
0VM415877
A20 A PANEL, TRAY H9410UD 0VM101245
A20 B PANEL, TRAY H94A4UD 0VM416109
1B1 DECK ASSEMBLY CZD012/VM1640 N1640FL
1B2 DVD MECHA 0838 VCDVM040 N79F0GVM
2B1 DECK PEDESTAL-1 H9400UD 0VM101201-1
2B2 TOP BRACKET H9100UD 0VM203252A
2B3 SIDE BRACKET H9100UD 0VM305013
2B6 DECK PEDESTAL-2 H9400UD 0VM101201-2
2B7 DECK PEDESTAL-3 H9400UD 0VM101201-3
2B16 TAPE, HIMELON H9206JD 0VM413956
2B18 FIBER, TOP CASE HC460ED 0VM412906
2B23 M-PCB RUBBER H9400UD 0VM415762
2B40 INSULATOR H9400UD 0VM305872
2L011 SCREW, S-TIGHT M3X8 BIND + CHROME GBMS3080
2L012 SCREW, S-TIGHT M3X8 BIND + CHROME GBMS3080
2L021 SCREW, S-TIGHT M3X26 H9400UD 0VM414507
2L031 SCREW, S-TIGHT M3X5 BIND HEAD+ GBMS3050
2L032 SCREW, S-TIGHT M3X5 BIND HEAD+ GBMS3050
2L033 SCREW, S-TIGHT M3X5 BIND HEAD+ GBMS3050
2L034 SCREW, S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L041 SCREW, C-TIGHT M3X5 BIND HEAD + GBCC3050
2L051 SCREW, P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L052 SCREW, P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L054 SCREW, P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L055 SCREW, P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L061 SCREW, B-TIGHT M3X8 BIND HEAD + GBKB3080
2L062 SCREW, B-TIGHT M3X8 BIND HEAD + GBKB3080
2L071 SCREW, P-TIGHT M3X10 WASHER HEAD+ GCMP3100
2L081 SCREW, S-TIGHT M3X5 BIND HEAD + GBKS3050
2L082 SCREW, S-TIGHT M3X5 BIND HEAD + GBKS3050
2L091 SCREW, P-TIGHT M3X8 BIND HEAD+ GBCP3080
PACKING
S1 A GIFT BOX CARTON H9410UD 0VM306061A
S1 B GIFT BOX CARTON H94A4UD 0VM306665
S2 STYROFOAM(2) H9100UD 0VM203377C
S3 UNIT, BAG E5500UD 0VM411683
ACCESSORIES
X1 REMOTE CONTROL UNIT 364/CRC007 or NA209UD
REMOTE CONTROL UNIT 364/CRC007 NA259UD
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CABLE 2.5C-2V WPZ0901TM002
X4 ACCESSORY BAG H3600UD T=0.03 0VM409454
X5 AV CORD TSCKA-Y/RW100 or WPZ0102TM015
AV CORD RCA(M*2)TO RCA(M*2) WPZ0102LTE01
X20# A OWNER'S MANUAL H9410UD 0VMN03468
X20# B OWNER'S MANUAL H94A4UD 0VMN03884
X36 RETURN STOP SHEET H9410UD 0VM414898
X46 DVD RENTAL SHEET H9410UD 0VMN03694
Ref. No. Mark Description Part No.
