20031110 3-3-1 H94X1EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
3. LED Type :
When it is necessary to replace one or more of the
following diodes, all six should be replaced: D564,
D565, D566, D567, D2001 and D2002 on the Main
CBA.
DVD MAIN CBA UNIT
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DVD MAIN CBA UNIT N7BFNGUP
Ref. No. Description Part No.
MCV CBA
Consists of the following
0VSA14670
MAIN CBA (MCV-A)
FUNCTION CBA (MCV-B)
DVD OPEN/CLOSE CBA(MCV-C)
DVD SW CBA(MCV-D)
SENSOR CBA
--------------
--------------
--------------
--------------
0VSA13627
Ref. No. Description Part No.
MAIN CBA(MCV-A)
Consists of the following
----------
CAPACITORS
C023 ELECTROLYTIC CAP. 100µF/25V M or CE1EMASDL101
ELECTROLYTIC CAP. 100µF/25V M CE1EMASTL101
C051 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C053 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101
C060 CERAMIC CAP.(AX) B K 0.1µF/25V CCA1EKT0B104
C253 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C255 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V or CZM1CZB0F103
CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZ30F103
C256 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C257 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZB0F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C308 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C309 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C310 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZB0F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C311 CHIP CERAMIC CAP. CH J 390pF/50V or CHD1JJBCH391
CHIP CERAMIC CAP. CH J 390pF/50V or CHD1JJ3CH391
CHIP CERAMIC CAP. CG J 390pF/50V CHD1JJ3CG391
C312 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C314 CHIP CERAMIC CAP.(MELF) SL J 100pF/50V or CZM1JJBSL101
CHIP CERAMIC CAP.(MELF) SL J 100pF/50V CZM1JJ3SL101
C315 CHIP CERAMIC CAP.(MELF) SL J 100pF/50V or CZM1JJBSL101
CHIP CERAMIC CAP.(MELF) SL J 100pF/50V CZM1JJ3SL101
C320 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C321 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C322 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C324 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C325 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C326 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C329 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V or CZM1CZB0F103
CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZ30F103
C330 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V or CZM1CZB0F103
CHIP CERAMIC CAP.(MELF) F Z 0.01µF/16V CZM1CZ30F103
C332 CHIP CERAMIC CAP. B K 0.01µF/50V or CHD1JKB0B103
CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C333 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C335 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZB0F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C336 CHIP CERAMIC CAP. B K 0.047µF/50V or CHD1JKB0B473
CHIP CERAMIC CAP. B K 0.047µF/25V or CHD1EKB0B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C337 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C339 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C340 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C341 CHIP CERAMIC CAP. B K 0.01µF/50V or CHD1JKB0B103
CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C344 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C345 CHIP CERAMIC CAP. B K 0.01µF/50V or CHD1JKB0B103
CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C346 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C347 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C348 CHIP CERAMIC CAP. B K 0.047µF/50V or CHD1JKB0B473
CHIP CERAMIC CAP. B K 0.047µF/25V or CHD1EKB0B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C349 CHIP CERAMIC CAP. B K 0.047µF/50V or CHD1JKB0B473
CHIP CERAMIC CAP. B K 0.047µF/25V or CHD1EKB0B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
Ref. No. Description Part No.
To Next Page
