22 SI-Ethernet User Guide
Issue: 1
5.10.2 Menu 2 - Ethernet Configuration
Table 5.6 Menu 2 parameters
Parameter Range Default Type
02.003 Network Status
Initializing (0),
Links Down (1),
DHCP In Progress (2),
No Address (3),
Ready (4),
Active (5)
RO Txt ND NC PT
02.004
Network Message
Count
0 to 65535 Messages/s
RO Num ND NC PT
02.005 DHCP Enable Off (0) or On (1) On (1) RW Bit US
02.006 IP Address
0.0.0.0 to
255.255.255.255
192.168.1.100 RW IP US
02.007 Subnet Mask
0.0.0.0 to
255.255.255.255
255.255.255.0 RW IP US
02.008 Default Gateway
0.0.0.0 to
255.255.255.255
192.168.1.254 RW IP US
02.009 Primary DNS
0.0.0.0 to
255.255.255.255
0.0.0.0 RW IP US
02.010 Secondary DNS
0.0.0.0 to
255.255.255.255
0.0.0.0 RW IP US
02.011 MAC Address
00:00:00:00:00:00 to
FF:FF:FF:FF:FF:FF
RO Mac ND NC PT
02.020 Priority Protocol
None (0),
Modbus TCP (1),
EtherNet/IP (2)
None (0) RW Txt US
02.021 Web Server Enable Off (0) or On (1) On (1) RW Bit US
02.022 Web Server Port 0 to 65535 80 RW Num US
02.024 Ethernet MTU 158 to 1500 Bytes 1500 Bytes RW Num US
02.025 Gateway Mode
Switch (0),
Gateway (1),
Strict Gateway (2)
Switch (0) RW Txt US
02.030 VLAN Enable Off (0) or On (1) Off (0) RW Bit US
02.031 Drive VLAN ID 0 to 255 0 RW Num US
02.035 Non cyclic enable Off (0) or On (1) Off (0) RW Bit US
02.036
Non cyclic base
parameter
0.00.000 to 0.59.999 0.00.000 RW SMP US
