Appendix B
Specifications
Software
Supported operating systems
Windows 8.0 and 8.1
Windows 7 (32- or 64-bit)
Windows XP Home or Professional (32-bit) SP3
USB 1.1 and USB 2.0 interface Drivers included
Application software
AMS Device Manager Version 11.5 or later
License
AMS Device Manager HSE license Part number AW7060HSE
Electrical
Power consumption (Mode 1) ≤ 0.2 W
Power consumption (Mode 2)
at 85 mA output current ≤ 2.5 W
at 50 mA output current ≤ 1.7 W
Power supply to a fieldbus segment
(in Mode 2)
85 mA at 10V
Environmental
Operating temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage temperature -40 °C to 85 °C (-40 °F to 185 °F)
Storage humidity 0 to 95% relative humidity
User's Manual May 2014
48
