8
Front Panel
IP65 protection
NEMA 4X
Panel surface
(maximum thickness 15 mm / 0.59 inch)
Mounting Clamp
2.1 General Description
2.2 EPLC9600-CHANNEL8 Front View and Dimensions of
96 mm / 3.78 inch
96 mm / 3.78 inch
12 ± 1 mm / 0.47 inch
84 mm / 3.31 inch
Maximum 15 mm / 0.59 inch
1 2
3
4
5
6
7 8
a/A
ü
Sym
+/-
.
