ENGLISH
2
SPECIFICATIONS
PROCESS INPUT
Universal Input Voltage / Current
Thermocouple
Thermoresistance
Voltage/ Current Input Types Selectable by parameters. 0...50mV Z ,
0...5V Z ,0...10V Z or 0...20mA Z,4...20mAZ
Measurement Range Please refer to Table-1 for selection of input
type and scale.
Accuracy ± 0,25% of full scale for thermocouple, thermoresistance
and voltage,± 0,70% of full scale for current.
Cold Junction Compensation Automatically ±0.1°C/1°C.
Line Compensation Maximum
Sensor Break Protection Upscale.
Sampling Cycle 3 samples per second.
Input Filter 0.0 to 900.0 seconds.
: TC, RTD, Z
(TC): L(DIN 43710) ,J , K , R , S , T , B , E and N
(IEC584.1)(ITS90) ,C (ITS90)
(RTD): PT-100 (IEC751)(ITS90) Z
:
:
:
:
: 10 Ohm.
:
:
:
CONTROL
Control Form: ON/OFF, P, PI, PD or PID
5A@250VV ( (
: 0/4 to 20 mA or 0/2 to 10V Z
(Control form can be
programmed by the user.)
OUTPUT
Standard Relay Outputs :3 pieces at resistive load) They
can be programmed as Control or Alarm output)
(Electrical Life 100000 operation(Full Load))
Analog Output
:
DISPLAY
Process Display
Set Value Display
Auto Tune) Manual Mode Automatic Mode
Control or Alarm Set Control or Alarm
Status
:
ESM-4435 : 10.1 mm Red 4 digits LED display
:
ESM-4435 : 8 mm Green 4 digits LED display
LEDS : AT ( ,M ( ), A ( ), PSET /
ASET1 / ASET2 ( ) , PO, AO1, AO2 (
) , °C /°F / V LEDS.
ENVIRONMENTAL RATINGS and PHYSICAL SPECIFICATIONS
Operating Temperature :
Humidity none condensing)
Protection Class P65 at front, IP20 at rear
Weight :
Dimensions : Depth
Panel Cut-Out :
0...50°C
: 0-90%RH (
: I
ESM-4435 : 170 gr.
ESM-4435 : (48 x 48mm, :87.5 mm)
ESM-4435 : (46 x 46mm)
SUPPLY VOLTAGE AND POWER
Must be determined in order.)
100-240 V V 50/60 Hz (-15%;+10%) -6VA
48V Z (-15% ; +10%) -6W
24V V 50/60 Hz (-15% ; +10%) -6VA
24V Z (-15% ; +10%) -6W
(
