EMKO TRANS-AMF - Input;Output and Timer Configuration; Configurable Input Selections; Configurable Output Selections; Timer Settings

22
Min
Default
Unit
CONF. INPUT-7 ( )Inputs->Conf. input-7
Max
30(dis)
10
4
20
0
2500
Sec
0
Input type
Polarity
Indication
Activation
Select from list
Active delay
0-Disable
1-UserConfigured(Digital)
2-SelectFromList(Digital)
3-Cabin Temperature(Anolog)
IfInput TypeisDigital
0-NormallyOpen(Close To Activate)
1-NormallyClose(Open To Activate)
IfInput TypeisUserConfigured
0-Status
1-WarningNon-Latching
2-WarningLatching
3-Electrical Trip
4-Shutdown
IfInput TypeisUserConfigured
0- ActiveFromStarting
1- ActiveFromSafetyOn
2- Always Active
Input active delay (If Input Type is Digital)
IfInput TypeisSelectFromList
0-RemoteStartOnLoad
1-RemoteStartOffLoad
2-AuxiliaryMainsFail
3-WorkingCalendar Active
4-Master AutoReady
5-Simulate AlarmResetButton
6-Simulate AutoButton
7-Simulate TestButton
8-SimulateManualButton
9-SimulateStartButton
10-SimulateStopButton
11-GeneratorClosed Auxiliary
12-GeneratorLoadInhibit
13-MainsClosed Auxiliary
14-MainsLoadInhibit
15-AutoRestoreInhibit
16-AutoStartInhibit
17-PanelLock
18-ScheduledRuns(Exercise)Inhibited
19-PrioritySelect
20-Transfer ToGenerator/OpenMains
21-Transfer ToMains/OpenGenerator
22-RemoteInhibit
23-BeingFound Alive
24-LowBattery
25-SprinklerModeOnLoad
26-SprinklerModeOffLoad
3
Cabin temp.low prealr
Cabin temp.low reset
Cabin temp.low shutd.
Cabin temp.high preal
Cabin temp.high reset
Cabin temp.high shutd
5
Cabin temperature low prealarm
Cabin temperature low prealarm reset
Cabin temperature low shutdown
Cabin temperature high prealarm reset
Cabin temperature high prealarm
Cabin temperature high shutdown
100
100
100
100
100
100
ºC
ºC
ºC
ºC
ºC
ºC
dis
0
dis
dis
0
dis
-50(dis)
-50
-50(dis)
-50(dis)
-50
-50(dis)
0
0
2
26 8
Note: dis=disable
