EMKO TRANS-AMF - Parameter Value Modification; Navigating Parameter Sections; Changing and Saving Values

24
4.2.6Outputs
Min
Default
Unit
CONF. OUTPUT-1 ( )Outputs->Conf. output-1
Max
010
1380 43
Polarity
Function
0-NormallyOpen(Close To Activate)
1-NormallyClose(Open To Activate)
0-NOT USED
1-AIRFLAP CONTROL
2-ALARMRESET
3-AUDIBLE ALARM
4-AUTOSTART INHIBIT
5-AUXILIARY MAINSFAILURE
6-BATTERY HIGHVOLTAGE
7-BATTERY LOWVOLTAGE
8-CALLINGFORSCHEDULEDRUN(EXERCISE)
9-CANECUPOWER
10-CANECUSTOP
11-CHARGE ALTERNATORFAILURE
12-COMMON ALARM
13-COMMONELECTRICAL TRIP ALARM
14-COMMONSHUTDOWN ALARM
15-COMMONWARNING ALARM
16-COOLINGFAN AFTERSTART
17-COOLINGFAN AFTERSTOP
18-COOLANT TEMPERATUREHIGHPRE-ALARM
19-COOLANT TEMPERATUREHIGHSHUTDOWN
20-COOLINGDOWN TIMERINPROGRESS
21-CRANKRELAY ENERGISED
22-DELAYED ALARMS ACTIVE
23-DIGITAL INPUT1 ALARM
24-DIGITAL INPUT2 ALARM
25-DIGITAL INPUT3 ALARM
26-DIGITAL INPUT4 ALARM
27-DIGITAL INPUT5 ALARM
28-DIGITAL INPUT6 ALARM
29-DIGITAL INPUT7 ALARM
30-EXPANSIONINPUT1 ALARM
31-EXPANSIONINPUT2 ALARM
32-EXPANSIONINPUT3 ALARM
33-EXPANSIONINPUT4 ALARM
34-EXPANSIONINPUT5 ALARM
35-EXPANSIONINPUT6 ALARM
36-EXPANSIONINPUT7 ALARM
37-EXPANSIONINPUT8 ALARM
38-EARTHFAULT
39-EMERGENCY STOP
40-FAIL TOSTART ALARM
41-FAIL TOSTOP ALARM
42-CONF. AI1CONTROL
43-FUEL RELAY ENERGISED
44-GASENGINEIGNITIONOUTPUT
45-GENERATOR AT REST
46-GENERATOR AVAILABLE
47-GENERATORCLOSED AUXILIARY
48-GENERATORFAILED TOCLOSE
49-GENERATORFAILED TOOPEN
50-GENERATORHIGHFREQUENCY PRE-ALARM
51-GENERATORHIGHFREQUENCY SHUTDOWN
52-GENERATORHIGHVOLTAGEPRE-ALARM
53-GENERATORHIGHVOLTAGESHUTDOWN
54-GENERATORLOADINHIBIT
55-GENERATORLOWFREQUENCY PRE-ALARM
56-GENERATORLOWFREQUENCY SHUTDOWN
57-GENERATORLOWVOLTAGEPRE-ALARM
58-GENERATORLOWVOLTAGESHUTDOWN
59-GENERATORSTOPPING
60-GENERATOROPENBREAKER
61-HORNOUTPUT LATCHED
62-HORNOUTPUT PULSED
63-MASTER AUTOREADY
64-CONF. AI2CONTROL
65-LOSSOFMAGNETICPICK-UP SPEEDSIGNAL
66-LOW TEMPERATURE
67-MAINTENANCEDUE ALARM
68-MAINSCLOSED AUXILIARY
69-MAINSFAILED TOCLOSE
70-MAINSFAILED TOOPEN
71-MAINSFAILURE
72-MAINSHIGHFREQUENCY
73-MAINSHIGHVOLTAGE
74-MAINSLOADINHIBIT
75-MAINSLOWFREQUENCY
76-MAINSLOWVOLTAGE
77-MAINSOPENBREAKER
78-NOLOADINGCOMMAND
79-OIL PRESSURELOWPRE-ALARM
80-OIL PRESSURELOWSHUTDOWN
81-CONF.AI1.HIGHPREA
82-CONF.AI1.HIGHSHUT
83-OVERCURRENT PRE-ALARM
84-OVERCURRENT
85-OVERPOWERPRE-ALARM
86-OVERPOWERSHUTDOWN
87-OVERSPEEDPRE-ALARM
88-OVERSPEEDSHUTDOWN
89-PANEL LOCK
90-PRE-HEAT(duringpreheattimer)
91-PRE-HEAT(untilendofcranking)
92-PRE-HEAT(untilendofwarming)
93-PRE-HEAT(untilendsafetyon)
94-REMOTESTART PRESENT
95-REMOTESTOP DELAY INPROGRESS
96-SHORT CIRCUIT
97-SMOKELIMITING
98-STARTING ALARM
99-STARTING ALARMS ARMED
100-STOP RELAY ENERGISED
101-SYSTEMIN AUTOMODE
102-SYSTEMINMANUAL MODE
103-SYSTEMINSTOP MODE
104-SYSTEMIN TEST MODE
105-UNDERCURRENT PRE-ALARM
106-UNDERCURRENT
107-UNDERPOWERPRE-ALARM
108-UNDERPOWERSHUTDOWN
109-UNDERSPEEDPRE-ALARM
110-UNDERSPEEDSHUTDOWN
111-WAITINGFORGENERATOR
112-DUAL COMMUNICATIONERROR
113-LOADSUPPLY FROMGENERATOR
114-LOADSUPPLY FROMMAINS
115-CONFIGURABLE ANALOGINPUT 1LOWPRE-ALARM
116 CONFIGURABLE ANALOGINPUT 1LOWSHUTDOWN
117-CONFIGURABLE ANALOGINPUT 2LOWPRE-ALARM
118-CONFIGURABLE ANALOGINPUT 2LOWSHUTDOWN
119-CONFIGURABLE ANALOGINPUT 2HIGHPRE-ALARM
120-CONFIGURABLE ANALOGINPUT 2HIGHSHUTDOWN
121-CHOKE ACTIVE
122-REMOTECONTROL ACTIVE
123-REVERSEPOWER
124-CABIN TEMPERATURELOWPRE-ALARM
125-CABIN TEMPERATURELOWSHUTDOWN
126-CABIN TEMPERATUREHIGHPRE-ALARM
127-CABIN TEMPERATUREHIGHSHUTDOWN
128-HEATERCONTROL
129-REMOTEOUTPUT
130-UNBALANCELOAD
131-WATERPUMP
132-RESERVED
133-RESERVED
134-RESERVED
135-RESERVED
136-SYNCHRONPOSITION
137-OVERLOADSTEP 1
138-OVERLOADSTEP 2
-
