Emmaljunga Super Viking - Bumper Bar Attachment and Release

54
Super Viking v. 2.3
13
12
14
15
12
13
11
12
Assembly and usage of seat unit
Assembly of the bumper bar
• Slot both attachments pieces located at each end of the bumper
bar, on to the plastic pieces on the seat unit.
• The crutch strap is assembled around the bumper bar with the
popper.
WARNING
• Make sure that the bumper bar is attached when the child is placed
in the pram.
Repositioning of the bumper bar
• Lower the bumper bar and press it back into the reciever (13).
WARNING
• The bumper bar shall always be assembled when using the pram.
• Before use, make sure that the bumper bar is securely attached to
the seat unit.
Open the bumper bar
• Press the button (12) and open the bumper bar.
• The complete bumper bar can be removed by opening the bumper
bar on both sides.
WARNING
• Make sure that the bumper bar is attached when the child is placed
in the pram.
