EMMO Monta Pro - Seat, Frame & Drivetrain Torque

79
Recommended Torque Values
Area Tool Rec� torque
Handlebar
Stem clamp bolts 5 mm Allen 10 Nm
Stem faceplate bolts 5 mm Allen 6 Nm
Stem angle adjustment bolt (side) 5 mm Allen 12 Nm
Stem angle adjustment bolt (bottom) 5 mm Allen 15 Nm
Speedometer clamp bolts 3 mm Allen 3 Nm
Remote clamp bolt 3 mm Allen 3 Nm
Throttle clamp bolt 3 mm Allen 3 Nm
Shifter clamp bolt Phillips or flat head 6 Nm
Brake lever clamp bolts 5 mm Allen 6 Nm
Brake
Caliper adapter to frame 5 mm Allen 6–8 Nm
Caliper to adapter 5 mm Allen 6–8 Nm
Brake pads to caliper Cotter pin n/a
Brake rotor to hub T25 Torx bit 7 Nm
Seat
Seat adjustment bolt 6 mm Allen 15 Nm
