Emotron VS10 Instruction

16
4
Mounting
Electrical installation
1-phase mains connection 230/240 V
4.3.2.1 Fusing and terminal data
Inverter
VS10231P7
VS10232P4
VS10233P2
VS10234P2
VS10236P0
VS10237P0
VS10239P6
Cable installation in
compliance with
UL
Operation
without mains choke
Fuse
Characteristic
all acc. to UL 248/CC
Max. rated current
A
15
15
15
15
30
30
30
Circuit breaker
Characteristic
Max. rated current
A
15
15
15
15
30
30
30
Operation
with mains choke
Fuse
Characteristic
all acc. to UL 248/CC
Max. rated current
A
15
15
15
15
30
30
30
Circuit breaker
Characteristic
Max. rated current
A
15
15
15
15
30
30
30
Earth-leakage circuit
breaker
≥ 30 mA, type A or B
Mains connection
Connection
X100
Connection type
Screw terminal
Min. cable cross-section
AWG
18
Max. cable cross-section
AWG
12
10
Stripping length
inch
0.32
Tightening torque
lb-in
4.4
6.2
Required tool
0.5 x 3.0
0.6 x 3.5
Motor connection
Connection
X105
Connection type
Screw terminal
Min. cable cross-section
AWG
18
Max. cable cross-section
AWG
12
Stripping length
inch
0.32
Tightening torque
lb-in
4.4
Required tool
0.5 x 3.0
PE connection
Connection
PE
Connection type
PE screw
Min. cable cross-section
AWG
18
Max. cable cross-section
AWG
10
Stripping length
inch
0.39
Tightening torque
lb-in
11
Required tool
0.8 x 5.5
