Emotron VSA Series User Manual

42 Wiring notes Emotron AB 01-3991-11r2
Control signal terminals block description
Fig. 11 Signal terminal locations
Ta bl e 1 9
Symbol Description
RA
Multi-functional output terminal
Normally open contact
Rated contact capacity: (250 VAC/
10 A) Contact description: (refer to
menu [551])
RB
24V
PNP (SOURCE) input, S1 to S4 (S5/S6/S7) common terminal, (set
SW1 to PNP and connect option card power.)
S1
Multifunction input terminals (refer to [521] to [524] description)
S2
S3
S4
COM
NPN (SINK) input, S1 to S4 (S5/S6) common terminal, (set SW1 to
NPN, and analogue input, connect option card power, output signal
common terminal.)
10V Supply for external potentiometer for speed reference.
AIN
Analogue frequency signal input terminal or multifunction input termi-
nal S7 (high level: 8V/low level: 2V), adaptable to PNP (refer to [511]
description)
FM+
Multifunction analogue output + terminal (refer to [531] description),
output signal: DC 0-10V.
123456789101112
TM2
RA RB 24V S1 S2 S3 S4 COM 10V AIN COM FM+
