Wiring notes
Fuse types
Drive input fuses are provided to disconnect the drive from power in the event
that a component fails in the drive’s power circuitry. The drive’s electronic pro-
tection circuitry is designed to clear drive output short circuits and ground
faults without blowing the drive input fuses. The table below shows the VSC
input fuse ratings.
To protect the VSD most effectively, use fuses with current-limiting function.
RK5, CC/T TYPE FUSE FOR VSC
Fuse ratings are based upon 500V for 460V VSDs
• To avoid shock hazards, do not touch any electrical component when the
power is applied or until the power plug has been disconnected for five min-
utes. Other action should be performed after the change indicator goes off.
• Do not wire the on the VSD while it is still electrified. Disregarding this
could cause serious injury or death.
This product is designed for use in Pollution Degree 2 environment or equiva-
lent environmentsenvironments or equivalent.
VSC 48- HP KW KVA
100% CONT
Output
AMPS (A)
Max.RK5
FUSE
Rating(A)
Max.CC or T
FUSE
Rating(A)
440V
class (3φ)
009 5 3.7 6.7 8.8 20 30
013 7.5 5.5 9.9 13 25 35
018 10 7.5 13.3 17.5 30 50
To Next Page
