66 Software index Emotron AB 01-3990-11r3
5- Multifunction Input Terminals (MFIT)
Function
Code no.
Description Range/Code
Factory
setting
Re-
marks
5-00
Multifunction
Input Term. S1
0000: Forward/Stop Command *
1
0001: Reverse/Stop Command *
2
0002: Preset Speed #1 (6-02)
0003: Preset Speed #2 (6-03)
0004: Preset Speed #3 (6-05) *
3
0005: Jog
0006: Acc/Dec #2
0007: Emergency Stop A Contact
0008: Base Block
0009: Speed Search
0010: Energy Saving
0011: Control Signal Selection
0012: Communication Selection
0013: Acc/Dec Disabled
0014: Up Command
0015: Down Command
0016: Master/Auxiliary Speed
0017: PID Function Disabled
0018: Reset
0019: Encoder input terminal S5
0023: Analogue input terminal AIN
0024: PLC Application
0025: Traverse Run
0026: Traverse Run upper deviation
0027: Traverse Run lower deviation
0028: Power Source Detect for KEB
Function
0029: Emergency Stop B Contact *7
0000
5-01
Multifunction
Input Term. S2
0001
5-02
Multifunction
Input Term. S3
0002
5-03
Multifunction
Input Term. S4
0003
5-04
Multifunction
Input Term. S5
0004
5-05
Multifunction
Input Term. S6
0018
5-06
Multifunction
Input Term.
AIN
0023
5-07
Multifunction
Input Term. S1
to S6 Signal
Verification
Scan Time (ms
X 4)
1 to 100 5
