Dismantling
Cleaning
Re-Assembly
1. First, take off the oil container and the stainless baffle filters
2. Unscrew then remove the bottom cover of the hood.
3. Turn counter-clockwise to loosen the three screws in the
front right and left sides of the black base plate (oil pan), in
order to remove the base plate (oil pan).
4. Remove the rubber seal.
5. Turn clockwise to remove the vane cap.
6. Pull off the vane cap.
Immerse all the dismantled parts in water with neutral
detergent to 30 minutes, and then wash with a nylon brush.
Make sure that all parts are dry before reinstallation.
Note:
Dismantled parts are: oil container, base plate, vane and van
cap, and stainless steel baffle filters.
1. Re-assemble the vane (fan), and turn vane cap counter
clockwise to fasten, The vane must be locked onto the
motor’s pin.
2. Put on the rubber seal and screw the base plate to the body.
3. Reinstall the bottom panel, grease container, and stainless
baffle filters.
