6. TECHNISCHE SPEZIFIKATIONEN EA13000SPL
CLASS-D MONO VERSTÄRKER
1100W x 1 @ 4 Ohm (< 1.0% THD / 14.4V)
1950W x 1 @ 2 Ohm (< 1.0% THD / 14.4V)
3250W x 1 @ 1 Ohm (< 1.0% THD / 14.4V)
4000W x 1 @ 1 Ohm (< 1.0% THD / 16.0V)
4900W x 1 @ 1 Ohm (< 1.0% THD / 18.0V)
6500W x 1 @ 2 Ohm Master/Slave Betrieb (< 1.0% THD / 14.4V)
8000W x 1 @ 2 Ohm Master/Slave Betrieb (< 1.0% THD / 16.0V)
9800W x 1 @ 2 Ohm Master/Slave Betrieb (< 1.0% THD / 18.0V)
Full-MOS-FET Class-D Verstärker
Variables Subsonicfilter, 10 - 60 Hz mit 24dB/Okt.
Variables Tiefpassfilter, 30 – 300Hz mit 24dB/Okt.
Variabler Phase-Shift von 0 – 180°
Variable Eingangs-Empfindlichkeit von 0.3 – 7V
Dämpfungsfaktor an 4 Ohm: > 350
Signal-Rauschabstand: > 85dB
Externe Basspegel-Fernbedienung
50mm² Strom-Anschluss Terminals
Dimensionen BxHxT: 535 x 72 x 245mm
6. TECHNICAL SPECIFICATIONS EA13000SPL
CLASS-D MONO AMPLIFIER
1100W x 1 @ 4 ohms (< 1.0% THD / 14.4V)
1950W x 1 @ 2 ohms (< 1.0% THD / 14.4V)
3250W x 1 @ 1 ohms (< 1.0% THD / 14.4V)
4000W x 1 @ 1 ohms (< 1.0% THD / 16.0V)
4900W x 1 @ 1 ohms (< 1.0% THD / 18.0V)
6500W x 1 @ 2 ohms in master/slave mode (< 1.0% THD / 14.4V)
8000W x 1 @ 2 ohms in master/slave mode (< 1.0% THD / 16.0V)
9800W x 1 @ 2 ohms in master/slave mode (< 1.0% THD / 18.0V)
Full MOS-FET class-D amplification circuitry
Variable subsonic highpass filter, 10 – 60Hz with 24dB/oct.
Variable lowpass filter, 30 – 300Hz with 24dB/oct.
Fully variable phase-shift 0 – 180°
Variable input sensitivity: 0.3 – 7V
Damping factor @ 4 ohms: > 350
Signal to noise ratio: > 85dB
Low pass level remote control
50mm² direct power input terminals
Dimensions WxHxD: 535 x 72 x 245mm
