1. DESIGN FEATURES
■ CAR AUDIO AMPLIFIER: This EMPHASER class-D amplifier allows the cross-over controlled
amplification of subwoofer systems
■ DASH-MOUNT REMOTE LOWPASS LEVEL CONTROL: A compact „Lowpass-Level“ remote
control unit can be mounted close to the drivers seat. This control device allows the convenient level
adjustment of the bass volume.
■ DIGITAL AMPLIFICATION: This EMPHASER amplifier features an extremely efficient class-D
circuitry layout, to guarantee excellent sonic performance and very high power output.
■ 4 / 2 / 1 OHM LOAD STABILITY: This EMPHASER amplifier works totally stable into impe-
dance loads down to 1.0 ohms. The high damping factor guarantees full control over the connected
subwoofer system.
■ INTEGRATED ELECTRONIC CROSSOVER: The internal crossover section features fully variable
subsonic and lowpass filters with crossover slope rates of 12/24 dB/octave.
■ VARIABLE PHASE-SHIFT: This amplifier features a variable phase-shift control option, that
allows to adjust the output signal from 0 to 180°.
■ MASTER – SLAVE CONFIGURATION: Two EA1350D/EA1800D can be connected together,
to obtain an ultra high output power twin-amp configuration.
■ UNCOMPROMISING DESIGN AND CONSTRUCTION: Only best electrical and electronic
components have been used for the assembly of this amplifier line. Such as double-sided glass-fiber
epoxy circuit boards equipped with high current TR output devices.
■ ADVANCED PROTECTION CIRCUITRY: The protection circuitry safe-guards the amplifier
from short-circuits at the speaker outputs, DC offset voltage at the outputs and overheating of power
electronics.
■ STATUS AND PROTECTION LED’S: A green and a red LED located at input the side panel
enable you to monitor the operating status of your EMPHASER amp.
■ ADJUSTABLE INPUT SENSITIVITY: Each RCA line-input pair accepts input voltages from
300mV to 7V, providing a good match with the line-output levels of almost any head-unit on the
market.
