● The EM250 DRO is sophisticated piece of electronic equipment and should be carefully
handled and installed in order to avoid any potential damage.
● The rated supply to DRO should be within specified limits and should not be exceeded
under any circumstances. Doing so may cause irreversible damage to DRO.
● DRO should be opened by authorized person only. Otherwise it will invalidate the
warranty of the unit. If in any doubt or you believe the unit requires servicing please
contact info@ems-i.co.uk for assistance.
● It is highly recommended that the Equipotential Point (Ground) should be connected to
avoid potential for erratic operations through electrical noise in the working
environment.
● Cable routing of DRO and encoders should not be routed through or nearby high
capacity switching/inductive load or where it can cause danger. Avoid routing cables
with those of the motor, lighting or other such sources of potential RF and electrical
noise.
Please Read Before Proceeding
Warranty will be considered void if and not limited to:
Failing to meet manufacturers specified supply conditions.
Abusive handling.
Environmental conditions outside of Manufacturers specifications.
Manipulation, tampering of electronics.
Replacement of original parts with other parts than specified by manufacturer.
Used with encoders other than those supplied by the manufacturer.
Disposal
At the end of its life the EM250 DRO and systems should be disposed of in a safe an
environmentally sympathetic manner as applicable to local legislation. The casework and
other components may be suitable for recycling. DO NOT BURN.
Encoder Connections
Equipotential
Terminal
Tilt Mounting (M10)
IEC Mains Input
DRO On/Off Switch
- 3 -
Fuse (1A, 15W)
