EMS FirePoint 5000 Communications Guide

EMS 5000 FIREPOINT
©2015 EMS Security Group Ltd. All rights reserved. TSD234 Iss 3 25/06/15 AJM
6
4. Engineers Control Panel Quick Guide for Radio LAN Communication
|**Main Menu**|
Pins & Access
System Support
Serial Comms
Pager Setup
Engineers Ctrl
Time & Date
Output Setup
Logging
Remote Rxers
Ext.Comms
Bus I/O
Fire dbase
Checksum Data
Network Router
Radio LAN
Fire DB
^^^^^^^^^^^^^
|*Serial Comms*|
Device Table
Re-Start Bus
Re-Online Device
Bus Master Setup
Bus Remote Setup
Pager 232 Redir’
Aux 232 Redirect
Printer Redirect
Monitor Comms
Delete Device
^^^^^^^^^^^^^^^^
|*Master Setup*|
Polling Baudrate
Auto Re-online
Port to use
|*Remote Receivers*|
Receivers Found
Enable Receiver
Enable Collector
Monitor traffic
^^^^^^^^^^^^^^^^
Polling Baud
Is 384, Enter rate
(MAX 768):
YES = Finish TIME
Master Port =1
0=Off, 1 = RS485
2=PAGER 232
Local NUA : 00
Input Local NUA
YES = Finish TIME
|*Network Router*|
Setup local NUA
View Network NUA
Network Name
Control Routing
Send Test
Rem Rxer : DISABLED
Push YES to change
Push NO to escape
Push YES/NO TIME
Collector : ENABLED
Push YES to change
Push NO to escape
Push YES/NO TIME
Routing : ENABLED
Push YES to change
Push NO to escape
Push YES/NO TIME
|***Radio LAN***|
Node Table
Re-Start LAN
Re-Online Node
Node Setup
Add/Delete Node
Advanced
^^^^^^^^^^^^^^^^
|*** Node Setup ***|
Node Address: 1
Set as: Master
Site ID:2047
LAN Module NUA: 04
Auto Log ON: OFF
^^^^^^^^^^^^^^^^^^^^
|* Remote Setup *|
Reply Baudrate
Port to use
^^^^^^^^^^^^^^^^^^
Remote Port = 0
0 = Off, 1 = RS485
2 = PAGER232 >
| *** Advanced *** |
Poll Int: 60
Init Poll Int: 10
Poll Timeout: 3600
Delete All Nodes
Clear Missed Polls
Monitor Node
^^^^^^^^^^^^^^^^^^
**Note** The Poll
Int Timer Values
will vary. Please
refer to the table
on page 13 for
the applicable
value
Re Initialising Bus
Please wait *Done*
Push any key to continue
Enter Node Address
(Numbers 2-30)
Number > _
Yes = Finish TIME
Monitor Node
(Numbers 2-30)
Number > _
Yes = Finish TIME
| *** Delete Node *** |
Slot : 2
NONE
Slot : 3
ONLINE
Slot : 4
ONLINE
