Emtek Classic - Preparation; Door Prep; Door Jamb Prep

3
2-⁄” or 2-3/4” Backset
2 ⁄” Diameter Bore
⁄” Deep
2 ¼”
1 “
1” Diameter Edge Bore
2. Door Jamb Prep
1. Door Prep
Preparation
Step 1: Fasten Security Plate using two #10 x 3” Wood Screws (item #9).
Step 2: Fasten Strike Plate using two #8 x ¾” Wood Screws (item #6).
2-3/4"
#10 x 3” Wood Screws
⁄” Deep
2 ¾”
1 ⁄”
¾”
#8 x ¾” Wood Screws
1¼”
1¼” Deep
