EMX WEL-200 - Specifications

WEL-200™ Operating Instructions 3
Document no. 10320104 Revision 2.0 3-1-18
Specifications
WEL-200R
WEL-200T
Operating Range
Up to 200 ft. (line of sight)
Operating Frequency
915MHz
Response Time
100ms
Power/Fault Indicator
Red power LED/green
channel LED
Green transmit/status LED
Channel Status Indicator
Green LED
NA
Channel mode selection switch
Assign each channel to
OPEN/CLOSE function
NA
Outputs
 OPEN direction relay:
Form C contacts (NO,
COM, NC)
 CLOSE direction relay:
Form C contacts (NO,
COM, NC)
 OPEN direction – 300Hz
pulsed: Open collector
transistor output
(opto-isolated)
 CLOSE direction – 300Hz
pulsed: Open collector
transistor output
(opto-isolated)
NA
Resistive termination
10K ohm across NO contact
(jumper selectable)
NA
Power protection
Thermal fuse, MOV
Thermal fuse
Environmental Rating
NEMA 4X
Power Supply
12-24 VAC/VDC
3-3.6 VDC (2x AA batteries)
(ANSI 15-LF, IEC-FR14505
(FR6))
Battery life
NA
2 years at 25°C
Current Draw
50 mA
NA
Operating Temperature
-40°…60°C (-40°…140°F)
Dimensions (L x W x H)
140mm (5.5”) x 34mm (1.3”) x
90mm (3.5”)
180mm (7.0”) x 32mm (1.3”) x
67mm (2.6”)
Weight
200g (7 oz.)
170g (6 oz.)
Connections
12 terminals (18-26AWG)
2 terminals (18-26AWG)
