Encore EE48FR691V32 User Manual

18
SPECIFICATIONS
MODEL NUMBER
EE52FR691V32
EE52FR691V32CA
WEIGHT & DIMENSIONS
48”
52”
Width Without Deck
47.8
49.8”
Width – Deflector Up
48.8”
52.8”
Width – Deflector Down
59.9”
65.4”
Length
77.4”
77.4”
Height – ROPS Up
73”
73”
Height – ROPS Down
53”
53”
Wheelbase
50.3”
50.3”
Curb Weight
941 lbs
951 lbs
ENGINE
Kawasaki FR691V
Specs: See your Engine Owner’s Manual
RPM: High Idle: 3600
Low Idle: 1550
FUEL SYSTEM
• Capacity: 9.5 Gal
• Type of Fuel: Regular Unleaded Gasoline
87 Octane or higher
• Fuel Filter: In-line
ELECTRICAL SYSTEM
• Charging System: 12 Volt, 15 Amp @
3600 RPM
• Battery Type: Group Ul
• Battery Class: 280 CCA Minimum
• Battery Voltage:12V DC
• Polarity: Neg. Ground
• Fuses: (1) 20A Main
• (1) 15A Clutch
TRANSMISSION
Two Hydro Gear® integrated transaxles
• Hydraulic Oil: 20w-50 Non- Synthetic
• Speed:
o ZT-3200
▪ 0-9.0 mph Fwd
▪ 0-4.8 mph Reverse
CUTTING DECK
• Cutting Width: 48” & 52”
• Discharge: Side
• Blade Size: 48” - 16.25”/52” - 18”
• Deck Drive: Electric Clutch
• Deck: 7 ga Welded Steel Floating Deck
• Deck Depth: 5.5”
• Cutting Height 1.5” to 4.75”Adjustment:
• Mulching Kit: Optional
TIRES
Front: (48): 13 x 5-6
(52): 13 x 6.50-6 Smooth
Pressure 12-14 psi (83-97 kPa)
Rear: (48): 23 x 9.5-12
(52): 23 x 10.5-12
Pressure 15 psi (103 kPa)
