Connections to gauges and host systems Tankvision
20 Endress+Hauser
– High reference accuracy: up to ±0.075%, as PLATINUM version: ±0.05%
Deltabar S is communicating via the industry standard protocol HART and can be
connected to the Tankvision Tank Scanner via the Tank Side Monitor or an HART to
Modbus converter e.g. by Moore Industries. For more information see TI000382P/00/EN.
•Liquicap M
The Liquicap M FMI5x compact transmitter is used for the continuous level measurement
of liquids.
– Suitable for interface measurement
Liquicap M is communicating via the industry standard protocol HART and can be
connected to the Tankvision Tank Scanner via the Tank Side Monitor or an HART to
Modbus converter e.g. by Moore Industries. For more information see TI00401F/00/EN.
• Whessoe ITGs
• Sakura Endress Float&Tape Transmitter TMD
• Sakura Endress TGM5000
• Sakura Endress TGM4000
• SWG70: Wireless HART gateway
• Modbus slave devices
As Modbus is an open protocol there are various system components available which can
be connected to Tankvision Tank Scanner. To do so the so called gauge definition file and
the Modbus map file need to be adapted to the needs. This is a standard procedure and
described in BA00339G/00/EN. Examples for such devices are HART to Modbus
converters, PLCs or other protocol converters e.g. Gauge Emulator by MHT.
Remote service access via the Endress+Hauser device configuration tool FieldCare is
supported for the following device combination:
• Tankvision Tank Scanner with Modbus or Sakura V1 communication
• Tank Side Monitor Modbus or Sakura V1 communication and SW version 02.04.00 or
later
• HART devices connected to Tank Side Monitor intrinsic safe HART bus and supporting
FDT/DTM
or
• Tankvision Tank Scanner with Modbus or Sakura V1 communication
• Proservo NMS5/7 (Modbus or Sakura V1 communication) with
– TCB-6 version 4.27E
– Graphical display operation module
– Modbus communication module COM-5, version 2.0 or
– V1 communication module COM-1 (SRAM-mounted), version 5.01
– HART devices connected to Proservo cannot be reached by FieldCare
