Tankvision Calculations
Endress+Hauser 73
8.11 Annex A.4
Example CTSh calculations
8.12 Documentation
Tank Type Vertical Cylindri-
cal
Vertical Cylindri-
cal
Vertical Cylindri-
cal
Spherical Vertical Cylindri-
cal
Vessel
Radius
n.a. n.a. n.a. 17.253 n.a.
Product
Level
n.a. n.a. n.a. 4.6 n.a.
α1 (apha) 6.2 x 10^-6 6.2 x 10^-6 0.000011 110 x 10^-7 6.2 x 10^-6
αs 4.01E-09 0 0 n.a. 4.01E-09
Tcal 60 °F 60 °F 15 °C 20 °C 60 °F
Tprod 300 °F 300 °F -43 °C 23.5 °C 88.3 °F
Tamb 70 °F 70 °F n.a. 74.5 °F
Ifs 0.875 0.875 1 1 0.875
CTSh 1.00279801 1.0026195 0.998724 1.000047 1.00032
Document Instrument Description
TI00419G/00/EN Tankvision Inventory Management System wich completely integ-
rated software for operation via standard web browser
TI01252G/00/EN Micropilot NMR81 Micropilot NMR8 Series intelligent tank gauges are
designed for high accuracy liquid level measurement in
storage and process applications. They fulfill the exac-
ting demands of tank inventory management, inventory
control, custody transfer, loss control, total cost saving,
and safe operation.
TI01253G/00/EN Micropilot NMR84
TI01248G/00/EN Proservo NMS80 Proservo NMS8x Series intelligent tank gauges are desi-
gned for high accuracy liquid level measurement in sto-
rage and process applications. They fulfill the exacting
demands of tank inventory management, inventory con-
trol, custody transfer, loss control, total cost saving, and
safe operation.
TI01249G/00/EN Proservo NMS81
TI01250G/00/EN Proservo NMS83
TI01251G/00/EN Tankside Monitor NRF81 Tankside Monitor NRF81 is a robust gateway for collec-
ting and integrating tank gauging data in storage and
process applications. It fulfills the exacting demands of
tank inventory management, inventory control, custody
transfer, loss control, total cost saving, and safe opera-
tion.
TI00452G/08/EN Proservo NMS5 Intelligent tank gauge with high accuracy performance
Liquid level, I/F, Density & Density Profile
TI00402F/00/EN Tank Side Monitor NRF590 Field device for tank sensor operation and monitoring
and for integration into inventory control system
TI00344F/00/EN Micropilot S FMR531 Continuous level transmitter for continuous and non-
contact precision level measurement. For custody trans-
fer and inventory control applications with NMi- and
PTB-approvals
TI01122F/00/EN Micropilot S FMR532
TI00344F/00/EN Micropilot S FMR533
TI01123F/00/EN Micropilot S FMR540 Continuous level transmitter for continuous and non-
contact precision level measurement. For custody trans-
fer and inventory control applications with NMi and PTB
approvals
TI00042G/08/EN Prothermo NMT539 Intrinsically safe multi-signal converter with precision
average temperature and water bottom sensor for
inventory control and custody transfer applications
