Endress+Hauser NXA820 - Page 67

Tankvision Calculations
Endress+Hauser 67
General Purpose Regis-
ter 07
GP07 GP07 2607 N.A. Measured
General Purpose Regis-
ter 08
GP08 GP08 2608 N.A. Measured
General Purpose Regis-
ter 09
GP09 GP09 2609 N.A. Measured
General Purpose Regis-
ter 10
GP10 GP10 2610 N.A. Measured
General Purpose Regis-
ter 11
GP11 GP11 2611 N.A. Measured
General Purpose Regis-
ter 12
GP12 GP12 2612 N.A. Measured
General Purpose Regis-
ter 13
GP13 GP13 2613 N.A. Measured
General Purpose Regis-
ter 14
GP14 GP14 2614 N.A. Measured
General Purpose Regis-
ter 15
GP15 GP15 2615 N.A. Measured
General Purpose Regis-
ter 16
GP16 GP16 2616 N.A. Measured
Protocol Alarm 1 PROTOCOL_ALARM
_1
PROTOCOL_ALARM
_1
2650 N.A. Measured
Protocol Alarm 2 PROTOCOL_ALARM
_2
PROTOCOL_ALARM
_2
2651 N.A. Measured
Protocol Alarm 3 PROTOCOL_ALARM
_3
PROTOCOL_ALARM
_3
2652 N.A. Measured
Protocol Alarm 4 PROTOCOL_ALARM
_4
PROTOCOL_ALARM
_4
2653 N.A. Measured
Percentage Level PERCENTAGE_LEVE
L
PERCENTAGE_LEVE
L
2654 % Measured /
Calculated
VSP Volume VSP_VOLUME,2 VSP_VOLUME 2700 m
3
Calculated
Gauge Error GAUGE_ERROR GAUGE_ERROR 2755 N.A. Measured
Gauge Status GAUGE_STATUS GAUGE_STATUS 2756 N.A. Measured
Analog Input ANALOG_INPUT ANALOG_INP 2841 % Measured
HTMS Product Tempera-
ture
HTMS_P_TEMP HTMS_P_TEMP 2201 °C Calculated
Density Element 1 DENS_1 DENS_1 3001 kg/m
3
Measured
Density Element 2 DENS_2 DENS_2 3002 kg/m
3
Measured
Density Element 3 DENS_3 DENS_3 3003 kg/m
3
Measured
Density Element 4 DENS_4 DENS_4 3004 kg/m
3
Measured
Density Element 5 DENS_5 DENS_5 3005 kg/m
3
Measured
Density Element 6 DENS_6 DENS_6 3006 kg/m
3
Measured
Density Element 7 DENS_7 DENS_7 3007 kg/m
3
Measured
Density Element 8 DENS_8 DENS_8 3008 kg/m
3
Measured
Density Element 9 DENS_9 DENS_9 3009 kg/m
3
Measured
Density Element 10 DENS_10 DENS_10 3010 kg/m
3
Measured
Density Element 11 DENS_11 DENS_11 3011 kg/m
3
Measured
Parameter Name Gauge Map File
Name/
HostLink Param
Name
Report Tag Name Parameter
ID/
OPC Server
Comm ID
SI Unit Param Type
