Be careful to assemble all components
in the sequence they are presented.
A. Connect Upper Computer Cable B (#41), Hand Pulse Assembly C & D (#37
& #38), Touch Pad/Backlit Cable E(#43) and Groud Wire F (#35) to the board on
on back of the console (#28)
B. Attach Console Assembly (#28) to Console Support (#5) using:
Four M5x12mm Phillips Head Screws (#134)
Step 2
14
To Next Page
