Be careful to assemble all components
in the sequence they are presented.
A. Attached the console to Mounting Brackets (#3 & #4) using:
Six M8x12mm Socket Head Cap Screws (#146)
B. Connect Upper Computer Cable F (#41) to Lower Computer Cable A (#42)
C. Attach the Mounting Brackets (#3 & #4) to the Uprights using:
Six 3/8”-16 x 3/4” Button Head Socket Bolts (#145)
Six 3/8” Lock Washer (#117)
Six 3/8” Flat Washer (#125)
Step 3
16
To Next Page
