PART LIST
Pos nr.
Description
QTY
Remark
1
Inner-hex bolt
2
M5*45
2
Big wahser
2
M5
3
License plate holder
1
4
Rear light left
1
5
Left lamp protector
1
6
Lamp protector rotating spring
2
7
Lamp protector rotating fastener
2
8
Lamp rotating button
2
9
Uppon sliding Alu-tube
1
10
Plastic wheelholder left
1
11
Lockable strap frameohlder long
1
Ø30
12
Lockable strap frameohlder short
1
Ø30
13
Hexagon socket head shoulder bolt
2
M6*Ø8*85
14
Washer
4
M8
15
Special plastic washer
2
16
U-Tube
1
17
Hex-socket round head bolt
2
M8*100
18
Hex-socket round head bolt
2
M10*105
19
Hex-socket round head bolt
4
M6*60
20
Washer
8
M6
21
Quick connector cover
1
22
Quick connector
1
23
Back-cap of buttom sliding tube
2
24
Buttom sliding tube right
1
25
Front-cap of buttom sliding tube
2
26
Mid-sliding tube
2
27
Hex-bolt
4
M6*75
28
Linner tube
4
29
Back-cap top slidign tube
2
30
Plastic wheelholder right
1
31
Cap nut
6
M5
32
Spring washer
6
M5
33
Washer
6
M5
34
Right lamp protector
1
35
Carman rear light right
1
36
Hex-socket round head bolt
2
M5*35
37
Hex-socket round head bolt
2
M5*30
38
Lamp tilting subassembly
1
39
Cylinder nut
2
M6
40
Plastic handle
2
41
Buttom sliding tube left
1
42
Nylon-nut
4
M6
43
Washer
2
M10
44
Nylon-nut
2
M10
45
Nylon-nut
2
M10
46
Plastic base part for U-tube left
1
47
Plastic base part for U-tube right
1
48
Big washer
4
M6
49
Nylon-nut
2
M5
50
Lamp protector rotating fastener
2
51
Cylinder nut
2
M5
