5 Z100 Pioneer Thermostat Wiring
The following diagram shows the backplate of the Z100 Pioneer thermostat.
5.1 Conventional System
1
Common(GND)
C
8
2
Power (24VAC)
R
9
3
RS OUT
Outdoor Sensor
1st Stage Heat
W1
10
4
RS GND
Sensor Ground
Fan
G
11
5
FILTER
Filter
1st Stage Cool
Y1
12
6
2nd Stage Cool
Y2
13
7
2nd Stage Heat
W2
14
5.2 Heat Pump
1
Common (GND)
C
8
2
FAULT
Heat Pump Fault
Power (24VAC)
R
9
3
RS OUT
Outdoor Sensor
Auxiliary Heat
E
10
4
RS GND
Sensor Ground
Fan
G
11
5
FILTER
Filter
1st Stage Heat Pump
Y1
12
6
2nd Stage Heat Pump
Y2
13
7
Reversing Valve*
O/B
14
* Reversing Valve is also known as Changeover valve
