Energetics CT 680 - Assembly instruction; Step 3

13
Step 3
1. Assemble the upper cover (75) to handlebar post（17）.
2. Connect the upper (64) and lower computer cable (65), then fix the handlebar post (17) to
themainframe by bolts (15), flat washer (16) and curved washer (8).
Step-3
15
8
75
17
(b)
65
64
(a)
75
M8*15L
D22
(C)
M8*15L
D16
(x2)
(x4)
16
8
16
