Energetics CT 680 - Assembly instruction; Step 4

14
Step 4
1. Assemble the handlebar (36) to handlebar post (17) by T knob (41), flat washer (43), Spring
2. Washer (44), bushing (45) and protective cover (42).
3. The angle of handlebar can be adjusted by T knob (41).
4. Connect the handle pulse cable (34) an upper computer cable (64) to the cables from computer
(76).Then assemble the computer to handlebar post (17) by screws (99).
76
36
99
42
45
44
43
41
D
(x4)
M5*10L
UP
DOWN
Step-4
(a)
64
34
76
(b)
66
