Energetics CT 680 - Display Functions; Display Parameters Explained; Operating Procedure; Power On and User Setup

17
DISPLAY FUNCTION
TIME
Count up - No preset target, Time will count up from 00:00 to maximum 99:59
with each increment is 1 minute.
Count down - If training with preset Time, Time will count down from preset to
00:00.
Each preset increment or decrement is 1 minute between 00:00 to 99:00.
SPEED
Displays current training speed. Maximum speed is 99.9 KM/H or ML/H.
RPM
Displays the Rotation Per Minute. Display range 0~15~999
DISTANCE
Accumulates total distance from 0.00 up to 99.99 KM or ML. The user may
preset target distance data by using UP/DOWN button.
Each preset increment or decrement is 0.1KM or ML between 0.00 to 99.90 .
CALORIES
Accumulates calories consumption during training from 0 to maximum 9999
calories.
(This data is a rough guide for comparison of different exercise sessions which
can not be used in medical treatment.)
PULSE
User may set up target pulse from 0 - 30 to 230; and computer buzzer will beep
when actual heart rate is over the target value during workout.
WATT
Display current workout watts. Display range 10~350.
MANUAL
Manual mode workout.
PROGRAM
12 PROGRAM selection.
USER PROGRAM
User creates resistance level profile.
H.R.C
Target HR training mode.
WATT PROGRAM
WATT constant training mode.
Operating Procedure
POWER ON
Plug in power supply, computer will power on and
display all segments on LCD for 2 seconds (Drawing 1).
Drawing 1
Then enter into User data setting. Use UP or DOWN (Encoder) to select U1~U4, then set SEX, AGE,
HEIGHT (Drawing 2), WEIGHT and confirm by pressing MODE / ENTER key. When finishing user data
profile, Console come to main menu (Drawing 3).
Drawing 2
Drawing 3
