USER MANUAL
MPD-1007E
1. Optimal working conditions
Optimal working conditions
Environment Condition
Temperature 0 °C ~ 50 °C
Humidity 5 % ~ 90 % RH
Altitude
0 ~ 6,562 ft (2000 m) above sea level
installation category III and pollution degree 2
2. Introduction
MPD-1007E is a battery discharger and analyser designed to test the capacity of industrial batteries from 10 to 96 V with a
maximum discharge current of 200 A.
The main feature of the discharger/analyser is that it can function in two ways:
• The “Stand-alone” operation
• The system can be synchronised with all Replus models, allowing the discharge current to be increased up to 200 A.
The capacity of your batteries can be measured with high accuracy thanks to the built-in digital control. The discharge
current can be set between 0 and 200 A to perform a constant current discharge. The discharge process will stop when the
set voltage or discharge capacity has been reached, this protects your batteries from being over-discharged.
3. Specifications
Revision: 2017.08.29
AC input
Voltage range AC 200 - 240 V
Frequency 50 Hz / 60 Hz
Phase Single-phase
SYNCH with Replus regenerators
Replus support model
REF 100BA3558, REF 100BA3559,
REF 100BA3560
Current range 1 A – 200 A
Protocol interface RS-232
Discharge function support
Manual discharge mode
Program mode discharge &
restoration mode Pulse 3, 4
PC software support
YES, wireless communication support.
(use existing Replus operation method)
BMS (Battery monitoring
system) support
User interface
Display panel 128 x 64 mono-LCD
Interface switch Rotary & push switch
LED indicator
2 LED indicators:
power, discharging
Alarms
(Notices on display screen)
Battery connection
Reverse battery polarity
Environment
Operating temperature 0 °C – 50 °C (32 °F – 122 °F)
Humidity 5 % - 90 % RH
Mechanical
Dimensions / weight 45 kg
Accessories
Accessories 70 mm² x 1,5 m, SB-350
USB Provide USB
Protection
Battery polarity
reversal
If the terminals of the battery are connected in reverse,
an error message will be displayed on the MPD-1007E.
Equipment
protection
If the temperature of MPD-1007E gets too high, the
process will stop automatically.
Discharge functions
Voltage range DC 10 V – 110 V
Current range 1 A – 200 A (Constant current)
Accuracy
Current : 1,0 %
Voltage : 0,2 % – 0,5 %
Resolution
Current : 0,1 A
Voltage : 0,01 V
Discharge data transfer USB, Zigbee wireless (2,4 GHz)
