17
1. Setup the Battery: Remove the Battery Access Panel
from the unit by unscrewing the screw at the top and
releasing the panel.
2. Connect the Battery: locate and connect the loose
connectors from the battery wiring harness and the main
wiring harness. The battery is now connected to the unit.
3. Re-install the Battery Access Panel onto the unit.
Ensure the screw is fastened properly.
4. Remove the main engine access panel from the unit
by unscrewing the (4) screws at the top and middle of the
unit.
4.1 Initial Setup of Your Generator
We know you're excited to get using your generator. Please be sure to follow the setup,
operation, and shut off instructions below thoroughly to ensure the best lifespan for your
generator.
Steps 1-3 are for the EZV2800 only. If you have an EZV2200 start on Step 4.
