Ascent Oil – August 2019 15
FIGURE 2B – BOILER FEED and EXPANSION TANK LOCATION
FEEDWATER
CONNECTION
EXPANSION TANK TO
BE LOCATED IN
RETURN PIPING
ITEMS INSIDE PHANTOM BOX
NOT INCLUDED WITH SYSTEM
OPTIONAL TRIM KIT INCLUDES:
EXP TANK & FEEDER/PREVENTER
OPTIONAL PREMIER KIT INCLUDES:
FEEDER/PREVENTER
FIGURE 2B
