EnGenius ECB9500 Datasheet

TECHNICAL SPECIFICATION
> Hardware Specification
Expansion Slots N/A
Physical Interface
• LAN: One 10/100/1000Mbps
• Reset Button
• Power Jack
• WPS push button (Wi-Fi Protected Setup)
LEDs Status
• Power/ Status
• LAN (10/100/1000Mbps)
• WLAN (Wireless Connection)
Power Requirements
• Power Supply: 90 to 240 VDC ± 10％, 50/60 Hz (depends on different countries)
• Active Ethernet (Power over Ethernet, IEEE802.3af)- 48 VDC/0.375A
• Device: 12V/1A
Regulation Certifications • FCC Part 15/UL, CE
> RF Specification
Frequency Band 2.400～2.484 GHz
Media Access Protocol Carrier sense multiple access with collision avoidance (CSMA/CA)
Modulation Technology
- OFDM: BPSK, QPSK, 16-QAM, 64-QAM
- DBPSK, DQPSK, CCK
Operating Channels 11 for North America, 14 for Japan, 13 for Europe
Receive Sensitivity
(Typical)
- IEEE802.11n
MCS8 @ -91dBm
MCS15 @ -74dBm
- IEEE802.11g (3RX)
6Mbps@ -92dBm
54Mbps@ -75dBm
- IEEE802.11b (1RX)
1Mbps@ -93dBm
11Mbps@ -91dBm
Available transmit power
- IEEE802.11n/g
19dBm@6~9 Mbps / MCS9
18dBm@12~18 Mbps / MCS11
17dBm@24~36 Mbps / MCS13
16dBm@48~54 Mbps / MCS15
- IEEE802.11b
18dBm@1, 11Mbps
Antenna *3
Omni-directional external antenna
TNC type; Peak Gain = 5 dBi (Reverse)
Learn more about EnGenius Solutions at www.engeniustech.com.sg
Datasheet
ECB9500
BUSINESS CLASS
ECB9500
ECB9500 Datasheet Version 01222009
*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g, n chipset used. Actual throughput may vary.Network conditions and environmental
factors lower actual throughput rate.
** All specifications are subject to change without notice

EnGenius ECB9500 Specifications

General

Frequency band	2.4 - 2.484 GHz
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Antenna type	External
Antennas quantity	3
Antenna connector type	TNC
Antenna gain level (max)	5 dBi
Media access protocol	CSMA/CA
Ethernet LAN (RJ-45) ports	1
Compliance industry standards	FCC Part 15/UL, ETSI 300/328/CE
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	108 x 125 x 31 mm
