EnGenius ECB9500 Datasheet

> Management
Configuration
Web-based configuration HTTP / Telnet
Firmware Upgrade
Upgrade firmware via web-browser
Keep latest setting when f/w update
Administrator Setting
Administrator password change
Reset Setting
Reboot (press 1 second)
Reset to Factory Default (press 10 second)
System monitoring
Status, Statistics and Event Log
SNMP
v1, v2c
MIB
MIB I, MIB II (RFC1213) and Private MIB
Traffic Measurement
Per interface
Bandwidth Measurement
IP range and bandwidth management
Backup & Restore
Settings through Web
> Environment & Physical
Temperature Range
Operating: 0°C to 45°C (32°F to 113°F)
Storage: -20°C to 70°C (-4°F to 158°F)
Humidity (non-condensing) 5%～95% typical
Dimensions 125mm (L) x 108mm (W) x 31mm (H)
Weight 350g
Learn more about EnGenius Solutions at www.engeniustech.com.sg
Datasheet
ECB9500
BUSINESS CLASS
ECB9500
ECB9500 Datasheet Version 01222009
*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g, n chipset used. Actual throughput may vary.Network conditions and environmental
factors lower actual throughput rate.
** All specifications are subject to change without notice

EnGenius ECB9500 Specifications

General

Frequency band	2.4 - 2.484 GHz
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Antenna type	External
Antennas quantity	3
Antenna connector type	TNC
Antenna gain level (max)	5 dBi
Media access protocol	CSMA/CA
Ethernet LAN (RJ-45) ports	1
Compliance industry standards	FCC Part 15/UL, ETSI 300/328/CE
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	108 x 125 x 31 mm
