Engine G15 - Page 11

Replacement Parts
Engine Assembly
Replacement Parts G1597doc091819 4-2
4
G15
3 Pre-Cleaner, Kohler Air #52-083-01 014719 1
4 Filter, Kohler Oil #52-050-02 014717 1
Muffler Assembly, G13/G15 Kohler w/Arrestor 061128 1
5 Muffler Kit, G15 Kohler #12-786-16-S 061108 1 
6 Gasket, Kohler Muffler N/A 1
7 Arrestor, Kohler Spark 036684 1
8 Cage, Muffler Kohler #12-314-32-S
061109
2
1
Plug, Kohler Spark #12-132-02 (Champion #RC12YC) P12757 1
Filter, Kohler In-Line Fuel #25-050-02 014720 1
Switch, Kohler PHI Oil #25-099-24-S 051992 1
Solenoid, Kohler Starter #25-435-02-S 038425 1
Bypass Kit, Kohler Oil PSI #82-755-25-S 038426 1
Throttle and Clutch Parts (See Section 4.4
)
9 Hose, Oil Drain P10082 1
10 Cap, Oil Drain Hose P04332 1
11 Plate, LT15 Engine Guard 016493 1
12 Sheave, BK55QT 016512 1
13 Key, 1/4” X 1 11/16”
S04124
3
1
14 Bushing, QT x 1 016513 1
Harness Assembly, Battery To Engine 024718 1
15 BELT, BX87 DRIVE 017943 1
16 WASHER, 3/8” SAE FLAT F05011-3 4
17 WASHER, 3/8” SPLIT LOCK F05011-4 4
18 BOLT, 3/8-16 X 2 HEX HEAD GR5 F05007-124 4
19 Spacer, 17/32 x 1 1/2 x 3/4 034641 4
1
G15 engine option no longer available (3/11). Use conversion kit 065379 for service on LT15 Rev. E4.00 and later. Kit includes G18
Kohler engine, drive wheel, drive belt, tray, reduction kit and belt tensioner gauge. NOTE: Conversion kit will not work on LT15 prior
to Rev. E4.00.
2
016105 Square Muffler Cage no longer available (5/16). NOTE: Muffler Cage 061109 is a round cage and can be used only for new
engines equipped with the round muffler.
3
Replaces S21486 1/4” x 1” key. S04124 always used in production.
