Engine G15 - Throttle;Clutch Assembly

Replacement Parts
Throttle/Clutch Assembly
Replacement Parts G1597doc091819 4-8
4
G15
15 BOLT, 1/4-20 X 1/2” HEX HEAD F05005-15 1
16 NUT, 1/4-20 SWAGED F05010-21 1
17 BUSHING, 5/8” ID X 7/8” OD X 1 1/8” LONG FLANGED BRONZE 016486 2
18 BLOCK WELDMENT, LINKAGE CLUTCH/BRAKE 034612 1
19 PIN, 3/16 X 1 1/4 ROLL F05012-16 1
20 LINKAGE ASSEMBLY, W/BEARING 034605 1
21 Bushing, 5/8” ID x 7/8” OD x 1 1/8” Long Flanged Bronze 016486 1
22 NUT, 1/2-13 FREE HEX, ZINC F05010-35 1
23 WASHER, 1/2 SPLIT LOCK F05011-9 1
24 NUT, 1/2-13 JAM F05010-31 1
25 PIVOT WELDMENT, CLUTCH/BRAKE 034608 1
26 BUSHING, 1 X 1 1/4 X 3/4 FLG BRONZE P737 2
BRAKE/CLUTCH ASSEMBLY, LT15 034603 1
27 Arm Weldment, Clutch/Brake LT15 034613 1
28 Bolt, 3/8-16 x 2 Hex Head Gr5 F05007-124 1
29 Nut, 3/8-16 Hex Nylon Lock F05010-10 1
30 Block, LT15 Brake 016488 2
31 Screw, 10-24 x 1” Socket Head
F05004-2
1
4
32 Nut, #10-24 Keps F05010-14 4
33 Idler, 4" O.D. x 3/8 Bore 034602 1
34 Bolt, 3/8-16 x 2-3/4” Hex Head Gr5 Full Thread F05007-230 1
35 Washer, 3/8 Flat F05011-3 2
36 Nut, 3/8-16 Swaged Lock F05010-25 2
37 Spring, Idler Arm LT15/D/E/G 034810 1
1
Replaces F05004-50 originally supplied before 4/03 (duplicate part numbers).
