Engine G15 - Page 13

Replacement Parts
Engine Assembly
Replacement Parts G1597doc091819 4-4
4
G15
6 Gasket, Kohler Muffler N/A 1
7 Arrestor, Kohler Spark (Required w/Muffler) 036684 1
8 Cage, Muffler Kohler #12-314-32-S (Required w/Muffler #061108)
061109
2
1
Plug, Kohler Spark #12-132-02 (Champion #RC12YC) P12757 1
Filter, Kohler In-Line Fuel #25-050-02 014720 1
Switch, Kohler PHI Oil #25-099-24-S 051992 1
Solenoid, Kohler Starter #25-435-02-S 038425 1
Bypass Kit, Kohler Oil PSI #82-755-25-S 038426 1
Throttle and Clutch Parts (See Section 4.4
)
9 Hose, Oil Drain P10082 1
10 Cap, Oil Drain Hose P04332 1
11 Plate, LT15 Engine Guard 016493 1
12 Sheave, BK55QT 016512 1
13 Key, 1/4” x 1 11/16” S04124 1
14 Bushing, QT x 1 016513 1
Harness Assembly, Battery To Engine 024718 1
15 BELT, BX82 DRIVE 016505 1
16 Plate, LT15 Motor MOunt 016473 1
17 WASHER, 3/8” SAE FLAT F05011-3 4
18 WASHER, 3/8” SPLIT LOCK F05011-4 4
19 BOLT, 3/8-16 X 1” HEX HEAD F05007-7 4
1
G15 engine option no longer available (3/11). Use conversion kit 065379 for service on LT15 Rev. E4.00 and later. Kit includes G18
Kohler engine, drive wheel, drive belt, tray, reduction kit and belt tensioner gauge. NOTE: Conversion kit will not work on LT15 prior
to Rev. E4.00.
2
016105 Square Muffler Cage no longer available (5/16). NOTE: Muffler Cage 061109 is a round cage and can be used only for new
engines equipped with the round muffler.
