Engine G15 - Page 15

Replacement Parts
Engine Assembly
Replacement Parts G1597doc091819 4-6
4
G15
4 Filter, Kohler Oil #52-050-02 014717 1
5 Muffler Kit, G15 Kohler #12-786-16-S 061108 1
6 Gasket, Kohler Muffler N/A 1
7 Arrestor, Kohler Spark (Required w/Muffler) 036684 1
8 Cage, Muffler Kohler #12-314-32-S (Required w/Muffler #061108)
061109
1
1
Plug, Kohler Spark #12-132-02 (Champion #RC12YC) P12757 1
Filter, Kohler In-Line Fuel #25-050-02 014720 1
Switch, Kohler PHI Oil #25-099-24-S 051992 1
Solenoid, Kohler Starter #25-435-02-S 038425 1
Bypass Kit, Kohler Oil PSI #82-755-25-S 038426 1
9 Throttle and Clutch Parts (See Section 4.4
)
10 Hose, Oil Drain P10082 1
11 Cap, Oil Drain Hose P04332 1
12 Plate, G13/G15 Engine Mount 014810 1
13 Washer, 3/8” SAE Flat F05011-3 4
14 Washer, 3/8” Split Lock F05011-4 6
15 Bolt, 3/8-16 x 1” Hex Head F05007-7 4
Harness Assembly, Battery To Engine 024718 1
16 BOLT, 3/8-16 X 1 1/4” SPRING WASHER LOCK HEX HEAD F05007-131 4
17 ROD, BELT TENSION ADJUSTMENT 014975 1
18 NUT, 3/8-16 HEX F05010-1 2
19 BELT, BX81 014819 1
1
016105 Square Muffler Cage no longer available (5/16). NOTE: Muffler Cage 061109 is a round cage and can be used only for new
engines equipped with the round muffler.
