Engine G15 - Page 19

Replacement Parts
Throttle/Clutch Assembly
Replacement Parts G1597doc091819 4-10
4
G15
13 HANDLE, LT15 CLUTCH
016487
1
1
14 PIN, 3/16 X 1 1/4” ROLL F05012-16 1
15 BUSHING, 5/8” ID X 7/8” OD X 1 1/4” LONG FLANGED BRONZE 016486 2
16 BUSHING, 3/4” ID X 1” OD X 1 1/8” LONG FLANGED BRONZE 016485 4
17 PIN WELDMENT, MOTOR PIVOT 016477 1
18 NUT, 3/8-16 SWAGED LOCK F05010-25 1
19 BOLT, 3/8-16 X 3/4” HEX HEAD GRADE 2 F05007-27 1
20 SCREW, 7/16-20 X 1 1/2” SOCKET HEAD CAP F05007-55 2
21 WASHER, 7/16” SAE FLAT 15/16” OD F05011-43 1
22 BLOCK, MOTOR HANDLE PIVOT 016481 1
TURNBUCKLE ASSEMBLY, CLUTCH A12304 1
23 Nut, 7/16-20 Jam F05010-38 1
24 Rod End, 7/16-20 Right Hand Male P11579 1
25 Turnbuckle, 3" Clutch S11577 1
26 Nut, 7/16-20 Left Hand Jam F05010-87 1
27 Rod End, 7/16-20 Left Hand Male P11578 1
28 NUT, 7/16-20 JAM F05010-38 1
29 WASHER, 7/16” SPLIT LOCK F05011-48 3
30 NUT, 3/8-16 HEX NYLON LOCK F05010-10 2
31 WASHER, 3/8” FLAT SAE F05011-3 6
32 PLATE, LOWER TURNBUCKLE MOUNT 016472 1
33 NUT, 7/16-20 NYLON LOCK F05010-83 1
34 BOLT, 3/8-16 X 4 1/2” HEX HEAD F05007-35 2
35 SCREW, 10-24 X 1 1/2” SOCKET HEAD CAP BLACK OXIDE F05004-51 4
36 BLOCK, LT15 BRAKE 016488 2
37 NUT, #10-24 KEPS F05010-14 4
38 PIN, IDLER PIVOT 040102 1
39 PIN, 1/4” DIA LYNCH P113 1
40 SCREW, 1/4-20 X 1” HEX HEAD CAP F05005-38 1
41 SPRING, 3/8” OD X 4 1/2” LONG X .047” WIRE EXTENSION 016508 1
42 NUT, 1/2-13 JAM F05010-31 1
43 BOLT, 1/2-13 X 2” HEX HEAD GRADE 5
F05008-8
2
1
44 PLATE WELDMENT, BRAKE 016482 1
45 SPRING, EXTENSION 1/2” X 2 1/4” X .06” 014817 1
46 PLATE, LT15 MOTOR MOUNT 016473 1
1
Clutch Handle 016487 modified 3/07 to eliminate possible pinch point with feed rope pulley with saw head at certain heights.
2
Replaces F05008-33 1/2-13 x 1 1/2” Hex Head Bolt supplied prior to 10/00. Longer bolt provides more brake adjustment.
