Engine G15 - Page 21

Replacement Parts
Throttle/Clutch Assembly
Replacement Parts G1597doc091819 4-12
4
G15
CLUTCH/TURNBUCKLE KIT, LT15 SPRING-LOADED
016514
1
1
23 Clutch, LT15 w/Brake
014816
1
1 
Turnbuckle Assembly, LT15 Spring-Loaded Clutch 016446 1
24 Turnbuckle, LT15 Clutch 016443 1 
25 Plunger, LT15 Clutch Turnbuckle 016444 1
26 Spring, 3/4” OD x 3” Long x .095” Wire Compression 016492 1
27 Ring, 3/4” Inside Retaining F04254-34 1
28 Nut, 5/16-24 Hex F05010-28 2
29 Rod End, 5/16-24 Male Right-Hand P09814 2
Instruction Sheet, LT15 Clutch Turnbuckle Installation 016446-9561
Instruction Sheet, LT15 Clutch Installation 016514-957 1
30 BOLT, 5/16-18 X 1” HEX HEAD GRADE 2 F05006-1 1
31 SPACER, 1.016” X 1.5” X .56” S09174 1
BRACKET KIT, LT15G13 RETRO CLUTCH MOUNT
016437
1
32 Bracket, Clutch Mount 015979 1
33 Boss, 3/4 x 29/64 x 1 1/4” 015978 1
34 Washer, 7/16” Split Lock F05011-48 1
35 Bolt, 7/16-14 x 2” Hex Head Grade 5
F05007-139
1
36 WASHER, 5/16” SAE FLAT F05011-17 1
37 NUT, 5/16-18 HEX LOCK F05010-6 1
38 BOLT, 7/16-20 X 1” SOCKET HEAD
F05007-117
1
1
Kit includes Clutch and Spring-Loaded Turnbuckle. Use to retrofit LT15 prior to Rev. D3.00.
