Engine G15 - Page 23

Replacement Parts
Throttle/Clutch Assembly
Replacement Parts G1597doc091819 4-14
4
G15
22 BOLT, 5/16-18 X 1 1/2” HEX HEAD GRADE 5 FULL THREAD F05006-76 1
TURNBUCKLE ASSEMBLY, LT15 CLUTCH
014934
1
1 
23 Rod End, 5/16-24 Male Left-Hand 014815 1
24 Turnbuckle, 2 3/4” Clutch 014880 1
25 Nut, 5/16-24 Hex F05010-28 1
26 Rod End, 5/16-24 Male Right-Hand
P09814
2
1
27 BOLT, 5/16-18 X 1” HEX HEAD GRADE 2 F05006-1 1
28 SPACER, 1.016” X 1.5” X .56” S09174 1
29 CLUTCH, LT15 W/BRAKE
014816
3
1 
BRACKET KIT, LT15G13 RETRO CLUTCH MOUNT
016437
1
30 Bracket, Clutch Mount 015979 1
31 Boss, 3/4 x 29/64 x 1 1/4” 015978 1
32 Washer, 7/16” Split Lock F05011-48 1
33 Bolt, 7/16-14 x 2” Hex Head Grade 5
F05007-139
1
34 WASHER, 5/16” SAE FLAT F05011-17 1
35 NUT, 5/16-18 HEX LOCK F05010-6 1
36 BOLT, 7/16-20 X 1” SOCKET HEAD
F05007-117
1
1
Turnbuckle retrofit 016446 available 3/00 (See Section 4.6). Spring-loaded turnbuckle improves durability of the clutch and is easier
to adjust.
2
Replaces 014814 supplied before 5/98 (duplicate parts).
3
Clutch available only in kit 016514 including spring-loaded turnbuckle (See Section 4.6).
