Enraf Nonius 4 Series - Page 52

Page 52 of 72 EN109-1498751-47 IFU
Triangular pulsed current (ms)
t
p
Phase duration
t
i
Phase interval
Triangular pulsed current (Hz)
t
p
Phase duration
f
p
Pulse frequency
Galvanic current
Galvanic interrupted
f Carrier frequency - 8 kHz fixed
Duty cycle - 90 % fixed

Galvanic continuous
High voltage

t Peak interval - 64 µs fixed
f
p
Pulse frequency

Micro current
f Frequency
FIGURE 16
FIGURE 17
FIGURE 18
FIGURE 19
FIGURE 20
FIGURE 21
