and must therefore be avoided.
Connections Vacuum Cables
Electrotherapy channel 1
Connection point for the Vacuum Patient leads for
Channel 1.
Connections Vacuum Cables
Electrotherapy channel 2
Connection point for the Vacuum Patient leads for
Channel 2.
Interconnection cable vacuum
unit to main unit
Connection cable to connect the Vacuum unit with
the main unit.
Air inlet for draining the Vacuum Tank. See
instructions Vacuum Unit.
Connections [8] [9] [12] [13] are intended for the connection of type BF applied parts
complying with the leakage current requirements of IEC 60601-1.
Connections [10] [11] are intended for the connection of type B applied parts complying with
the leakage current requirements of IEC 60601-1.
