Enterasys B5K125-48 - B5 G124-48 and B5 G124-48 P2 Front Panel; B5 K125-24 and B5 K125-24 P2 Front Panel; B5 K125-48 and B5 K125-48 P2 Front Panel

Overview
Enterasys B5 Gigabit Ethernet Switch Hardware Installation Guide 1-3
Figure 1-2 B5G124-48 and B5G124-48P2 Front Panel
Figure 1-3 B5K125-24 and B5K125-24P2 Front Panel
Figure 1-4 B5K125-48 and B5K125-48P2 Front Panel
1 Switch status LEDs 4 RJ45 port status LEDs
2 RJ45 10/100/1000 Mbps ports 5 SFP port status LEDs
3 SFP slots 6 Console port
1 Switch status LEDs 5 RJ45 port status LEDs
2 RJ45 10/100/1000 Mbps ports 6 SFP port status LEDs
3 SFP slots 7 10G port status LEDs
4 10G slots 8 Console port
1 Switch status LEDs 5 RJ45 port status LEDs
2 RJ45 10/100/1000 Mbps ports 6 SFP port status LEDs
3 SFP slots 7 10G port status LEDs
4 10G slots 8 Console port
