ENTRON Controls, LLC. 700230D
10
3.1 Install and Setup
8. Beginning with default sengs, program a test-schedule with the following parameters below:
9. Run the test-schedule with the control in “No Weld” mode. Proper sequencing can be veried by monitoring the status page.
*Note: The display refresh me is 500ms; therefore any sequences less than 30 cycles (60Hz) or 25 cycles (50 Hz) might not be
displayed.
10. Once proper sequencing is veried, adjust ming cycles, inputs, and outputs as necessary.
PARAMETER SETTING
Squeeze Delay 0 cycles
Squeeze 60 cycles
Weld 1 0 cycles
Cool 1 0 cycles
Slope 0 cycles
Weld 2 8 cycles
>Mode Phase Shift
>Heat 25 %
Cool 2 0 cycles
Hold 60 cycles
Off 0 cycles
Impulses 0 cycle
