Entron EN6001 User Manual

3
ENTRON Controls, LLC. 700230D
3
1.1 Features
FEATURES:
• Calibrated constant current regulaon; Primary / Secondary feedback
• Current monitoring with high, low, and pre-limits
• Up to 64 programs (internal or 16 external selecon)
• On Timer Membrane Keyboard with backlit 128x64 (8 lines) LCD graphic display
• Six (6) inputs and four (4) outputs with output protecon on CPU
• Electrode management funcons, including stepping, p-dressing and preset curves
• Welding programs may be linked together for complex spot schedules (chained or successive)
• Refresh rmware through USB device
• Load/export control sengs from/to USB device
• AC 60/50 Hz welding supported
• Spot / Pulsaon / Seam welding / Flash or Bu welding / Brazing
• Mulple weld intervals plus pulsaon, upslope and downslope
• Air-over-oil gun operaon
• Retracon – maintained, and momentary
• Water Saver (contactor mer)
• Shorted contactor detecon
OPTIONS :
• Program Lockout (key switch)
• Operaon Mode Switch (Program Lockout and Weld/No Weld)
• Error Reset Switch
• Oponal plug-in Ethernet card provides PLC compability via MODBUS and Ethernet/IP for remote I/O (ENLink)
• AC Valve outputs
• Interlocking Door Solenoid (IDS)
• Full Phase Isolaon (FPI)
• Water Flow Switch (WFS)
• Schedule Number: 0 to 63
• Squeeze Delay: 0 to 99 cycles
• Squeeze: 0 to 99 cycles
• Valve Mode: None / All combinaons of 3 valves
• Weld1: 0 to 99 cycles
• Weld1: Phase Shi / Constant Current
• Heat1: 0 to 99%
• Current1: 0 to 100.00 kA
• Cool1: 0 to 99 cycles
• Slope: 0 to 99 cycles
• Weld2: 0 to 99 cycles
• Weld2: Phase Shi / Constant Current
• Heat2: 0 to 99%
• Current2: 0 to 100.00 kA
• Cool2: 0 to 99 cycles
• Hold: 0 to 99 cycles
• O: 0 to 99 cycles
• Impulses: 1 to 99 cycles
• Heat/Current Oset: -15 to +15%
• Cycle Mode: Non-repeat / Repeat / Chained / Successive /
Wait-here
SCHEDULE PARAMETERS:
